0.10mm Glass Cloth Adhesive Tape Acrylic Adhesive Tape For Electrical Insulation

MOQ:	500m2
Price:	by quote
Standard Packaging:	Each column shrink packed and then in export carton.
Delivery Period:	30days
Payment Method:	T/T,D/P,L/C
Supply Capacity:	10,000m2

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin

CHINA

Certification

Model Number

Backing Material:

E-fiber Glass Cloth

Backing Thickness:

100um

Total Thickness:

160um

Adhesive Type F-Class:

Acrylic Pressure-Sensitive

Adhesion To Steel:

≥4N/10mm

Tensile Strength:

≥200N/10mm

Elongation:

Breakdown Voltage F-Class:

≥1.8kV

Service Temp.:

-30°C ~ +150°C

Tack Rolling Ball:

≤10cm

Cut Roll:

10mm~500mm Width

Roll Length:

Highlight:

0.10mm glass cloth adhesive tape

acrylic adhesive electrical insulation tape

glass cloth insulation tape with warranty

Product Description

Product Description:

The Glass Cloth Adhesive Tape features a unique three-layer structure: a sturdy high-density glass cloth backing, coated with a high-performance pressure-sensitive acrylic adhesive that ensures powerful initial adhesion and long-lasting holding power, all protected by an easy-release silicone release paper for smooth unwinding and convenient application. This product is an ideal solution for your electrical insulation, mechanical fastening, and high-temperature protection applications.

Advantages:

Exceptional Durability: The backing is soft and tear-resistant, with good mechanical strength and high tensile strength, ensuring stable performance in demanding environments.
Powerful Adhesion: The high-quality acrylic adhesive provides outstanding adhesion and holding power, enabling strong bonds to various equipment and components.
Wide Temperature Range & Protective Properties: It features a service temperature range of -30°C to +150°C and possesses excellent insulation, explosion-proof, leak-resistant, and high-temperature protective properties, ensuring safety and reliability.

Technical Parameters:

Parameter	Value
Backing Material	E-fiber Glass Cloth
Backing Thickness	100 Micron
Total Thickness	160 Micron
Adhesion to Steel	≥4N/10mm
Tensile Strength	≥200N/10mm
Elongation	≥3%
Service Temp.	-30°C ~ +150°C
Breakdown Voltage F-Class	≥1.8kV
Adhesive Type F-Class	Acrylic Pressure-Sensitive

Applications:

Electrical Insulation & Fixation: Thanks to its strong adhesion and tensile strength, it is widely used for wrapping and binding transformer and motor coils, providing reliable insulation protection.
Battery Safety Protection: Its explosion-proof and leak-resistant characteristics make it ideally suited as an insulation wrapping layer for high-energy lithium-ion batteries, enhancing the safety of battery packs.
High-Temperature & Surface Protection: It can be used in various scenarios requiring high-temperature sandblasting protection or high-temperature shielding, protecting workpiece surfaces from damage.

Important Notes:

1. Storage & Shelf Life: 12 months when stored in a cool, dry place at 21°C (70°F) and 50% relative humidity, away from direct sunlight.
2. Surface Preparation: As with all pressure-sensitive tapes, the application surface must be thoroughly clean, dry, and free from contaminants such as grease or oil.
3. Product Use: Users are strongly advised to conduct thorough testing and trial applications to verify the product's suitability for their specific purpose and techniques.
