Acrylic 0.16mm Electrical PTFE Glass Adhesive Tape

Acrylic 0.16mm Electrical PTFE Glass Adhesive Tape
Acrylic 0.16mm Electrical PTFE Glass Adhesive Tape Acrylic 0.16mm Electrical PTFE Glass Adhesive Tape

Large Image :  Acrylic 0.16mm Electrical PTFE Glass Adhesive Tape

Product Details:
Place of Origin: CHINA
Brand Name: No
Certification: RoHS
Model Number: 652L
Payment & Shipping Terms:
Minimum Order Quantity: 3000m2
Price: by quote
Packaging Details: Export carton case
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 50,000m2 per month

Acrylic 0.16mm Electrical PTFE Glass Adhesive Tape

Adhesive Type: Acrylic Adhesive Base Material: Imported Glass Cloth
Releasing Paper: Yellow Releasing Paper (outside) Thermal Grade: F Class
Width: 10mm~500mm Length: 30m Or At Buyer's Request
Base Thickness: 0.10mm Total Thickness: 0.16mm
Adhesion Strength To Steel: ≥4N/10mm Ball Tack (14#): ≤10cm
High Light:

Electrical ptfe glass adhesive tape


0.16mm ptfe glass adhesive tape


Acrylic ptfe glass cloth tape

Glass Cloth Adhesive Tape ,F Grade ,Acrylic Adhesive Tape , 0.16mm Thick, Electrical Insulation


Base cloth: Imported E-glass cloth treated by PTFE emulsion

Adhesive: Silicone adhesive

Coating: Single side coated



Item Unit Standard valvue Test method standard
Base thickness mm 0.11± 0.005 ASTM D-3652
PTFE coating Thickness mm 0.02± 0.005 ASTM D-3652
Silicone adhesive Thickness mm 0.05± 0.005 ASTM D-3652
Total thickness mm 0.18±0.005 ASTM D-3652
Adhesive strength (to steel plate) N/100mm 22 ASTM D-3330
Tensile strength N/100mm 1560 ASTM D-3759
Elongation <5 ASTM D-3759
Surface friction coefficient   0.05~0.1
Electric resistance Ω ≧ 1012
Temperature resistance -70~260
Color Brown and black, or according buyer’s request

Product Features:

■ Working in the environment of -70℃~260℃, viscosity stable, working temperature 280℃ Maximum;

■ Non-sticking: smooth surface, easy to clean, oil non-stainable.

■ chemical corrosion resistance, acid and alkali resistance;

■ Electrical insulating and long service life.



1. Coating of various high temperature rollers, heating flat plates and stripping workpieces;

2. Heat sealing of food, medicine and plastic bags;

3. It can be used to paste linings such as chute, hopper, aviation mold, etc., and can also be applied to the drum of sizing machine, thermoplastic mold release and other industries. It can be used repeatedly and is easy to replace;

4. Applicable to other surface treatments that require anti-sticking, corrosion resistance and high temperature resistance;

5. It is used in packaging, thermoplastic, compounding, sealing and heat sealing, electrical and electronic industries.
