Product Description:
The Adhesive Insulation Tape is an essential product for various electrical insulation applications, offering reliable performance and durability. This industrial-grade fiberglass tape is designed with a pressure-sensitive acrylic adhesive, ensuring a strong and long-lasting bond.
The base material of this tape is made from high-quality E-Glass Fiber, with a thickness of 0.12mm for H-Class applications and 0.10mm for F-Class applications. This construction provides excellent electrical insulation properties, making it suitable for a wide range of industrial and commercial uses.
One of the key features of this Electrical Insulation Adhesive Tape is its wide operating temperature range. With an F-Class rating, it can withstand temperatures from -30°C to +150°C, ensuring reliable performance even in extreme conditions.
With a total thickness of 160 microns, this tape offers a good balance between strength and flexibility, making it easy to apply and conform to various surfaces. Whether you need to insulate electrical components, secure wire harnesses, or protect sensitive equipment, this tape provides a versatile solution.
Furthermore, the Adhesive Insulation Tape, we can provide some meets UL, IEC, and EU environmental standards, ensuring compliance with industry regulations and environmental requirements. This makes it a reliable and safe choice for applications where quality and performance are paramount.
In conclusion, the Adhesive Insulation Tape is a high-quality product that offers exceptional electrical insulation properties, strong adhesive bonding, and reliable performance in a wide range of temperatures. Whether you are a professional electrician, a maintenance technician, or a DIY enthusiast, this tape is a versatile and dependable solution for your insulation needs.
Features:
- Product Name: Adhesive Insulation Tape
- Total Thickness: 160 Micron
- Usage: Wrapping Transformer Coil Leads
- Operating Temperature F-Class: -30°C to +150°C
- Glass Cloth Thickness: 100 Micron
Technical Parameters:
| Adhesive |
Pressure-sensitive Acrylic Adhesive |
| Adhesion To Steel |
≥4N/10mm |
| Color |
White |
| Tensile Strength |
≥200N/10mm |
| Used As |
Insulation Wrap For High-energy Lithium Batteries |
| Operating Temperature F-Class |
-30°C to +150°C |
| Glass Cloth Thickness |
100 Micron |
| Breakdown Voltage F-Class |
≥1.8kV |
| Backing Material |
E-fiber Glass Cloth |
Applications:
Widely used for wrapping thransformer coil leads.
Explosion-proof and anti-leak properties of the glass tape, it is often used as insulation wrap for high-energy lithiu batteries.
Various high temperature sandblast protection
High temp. shield protection.
In terms of logistics, the delivery time of 30 days provides a reasonable lead time for orders, while the packaging details, including shrink packing and export cartons, ensure safe transportation of the product. The breakdown voltage specifications of the tape, including H-Class ≥2.5kV and F-Class ≥1.8kV, further highlight its reliability and performance.
Our Product Technical Support and Services for the Adhesive Insulation Tape include:
- Assistance with product installation and usage
- Troubleshooting common issues
- Providing guidance on proper storage and handling
- Recommendations for optimal applications
Packing and Shipping:
Product Packaging:
The Adhesive Insulation Tape is carefully packaged in a durable and moisture-resistant material to ensure its quality and protection during transportation and storage.
Shipping:
Orders of the Adhesive Insulation Tape are shipped within 20-25 business days after purchase. We use reliable shipping services to ensure that your product reaches you in a timely and secure manner. Tracking information will be provided so you can monitor the status of your delivery for the small quantity order.
FAQ:
Q: What is the model number of the Adhesive Insulation Tape?
A: The model number is 652L.
Q: Where is the Adhesive Insulation Tape manufactured?
A: The Adhesive Insulation Tape is manufactured in CHINA.
Q: What is the minimum order quantity for the Adhesive Insulation Tape?
A: The minimum order quantity is 500m2.
Q: How can I obtain the price for the Adhesive Insulation Tape?
A: The price is available upon quote request.
Q: What are the accepted payment terms for purchasing the Adhesive Insulation Tape?
A: The accepted payment terms are T/T, D/P, and L/C.
Q: What is the supply ability of the Adhesive Insulation Tape?
A: The supply ability is 10,000m2.
Q: What is the estimated delivery time for the Adhesive Insulation Tape?
A: The estimated delivery time is 30 days.
Q: How is the Adhesive Insulation Tape packaged?
A: Each roll is shrink packed and then placed in an export carton.
Q: Does the Adhesive Insulation Tape have any certifications?
A: Yes, the Adhesive Insulation Tape is RoHS certified.
