Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation
  • name
  • name
  • name

Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation

MOQ: 10000 sq.m
Price: by quote
Standard Packaging: pallet
Delivery Period: about 30 working days
Supply Capacity: 50000 sq.m per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Model Number
DFR-108B
Flame Retardant:
Yes
Composition:
2 Outer Layers Al Foil + FR Kraft Paper + Fiberglass Scrim
Foil Thickness:
7 Micron X 2 Layer
Adhesive:
Flame-retardant Glue
Highlight:

Grade D/S Foil Insulation

,

Reflective Aluminum Foil Insulation

,

Flame Retardant Reflective Foil Insulation

Product Description

It is commercial grade D/S foil insulation reflective aluminum foil insulation.



Product Description

Flame-retardant commercial grade D/S foil insulation. It is made from 2 outer layers of pure aluminum foil and 1 layer F/R kraft paper. These layers are bonded together with F/R glue and reinforced with 2-way 5x5mm fiberglass scrim. It is ideally used as sarking and insulation under roofs, in walls behind cladding or under timber floors, for residential and commercial building. Combining with glasswool/rockwool/mineral wool/foam insulation, it is excellent as a vapor barrier and reflective foil insulation for air-conditioning ducts, pipes and vessels.



Product construction

Composition Description Value (Metric)
Foil Aluminum 7 micron
Reinforcing - MD Fiberglass 5mm spacing
Reinforcing - XD Fiberglass 5mm spacing
Adhesive Flame-Retardant Glue ------
Kraft Flame-Retardant 90g/m2
Adhesive Flame-Retardant Glue ------
Foil Aluminum 7 micron



Advantage:

Fire rating Less 25 / 50 - Passed UL 723 / ASTM E84
Fire rating Class O - Passed BS 476 Pt 6 & 7
Tags:

0.12mm foil scrim kraft,

0.12mm fsk foil scrim kraft,
