Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation

Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation
Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation

Large Image :  Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation

Product Details:
Place of Origin: China
Model Number: DFR-108B
Payment & Shipping Terms:
Minimum Order Quantity: 10000 sq.m
Price: by quote
Packaging Details: pallet
Delivery Time: about 30 working days
Supply Ability: 50000 sq.m per month

Commercial Grade D/S Foil Insulation Reflective Aluminum Foil Insulation

Description
Flame Retardant: Yes Composition: 2 Outer Layers Al Foil + FR Kraft Paper + Fiberglass Scrim
Foil Thickness: 7 Micron X 2 Layer Adhesive: Flame-retardant Glue
High Light:

Grade D/S Foil Insulation

,

Reflective Aluminum Foil Insulation

,

Flame Retardant Reflective Foil Insulation

It is commercial grade D/S foil insulation reflective aluminum foil insulation.



Product Description

Flame-retardant commercial grade D/S foil insulation. It is made from 2 outer layers of pure aluminum foil and 1 layer F/R kraft paper. These layers are bonded together with F/R glue and reinforced with 2-way 5x5mm fiberglass scrim. It is ideally used as sarking and insulation under roofs, in walls behind cladding or under timber floors, for residential and commercial building. Combining with glasswool/rockwool/mineral wool/foam insulation, it is excellent as a vapor barrier and reflective foil insulation for air-conditioning ducts, pipes and vessels.



Product construction

Composition Description Value (Metric)
Foil Aluminum 7 micron
Reinforcing - MD Fiberglass 5mm spacing
Reinforcing - XD Fiberglass 5mm spacing
Adhesive Flame-Retardant Glue ------
Kraft Flame-Retardant 90g/m2
Adhesive Flame-Retardant Glue ------
Foil Aluminum 7 micron



Advantage:

Fire rating Less 25 / 50 - Passed UL 723 / ASTM E84
Fire rating Class O - Passed BS 476 Pt 6 & 7
