Aluminium Foil Scrim Tape
  • name
  • name
  • name
  • name

Aluminium Foil Scrim Tape

MOQ: 10,000squre meter
Price: by quote
Standard Packaging: Export carton case and pallet
Delivery Period: 30 working days
Supply Capacity: 50,000m2 per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Model Number
FSE18205BHK
Material:
High Performance Rubber Resin Adhesive
Backing Thickness:
0.150±0.015mm
Service Temperature:
-20 ~ +80 °C
Cut Roll Width:
48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4")
Backing Material:
Scrim Reinformed Al Foil 18um
Scrim Size:
5mmx5mm
Releasing Paper:
Craft Paper
Working Surface:
Rough Surface
Highlight:

Aluminium Foil Scrim Tape

,

0.15mm Foil Scrim Tape

,

0.15mm foil scrim kraft tape

Product Description

FSE18205BHK



High Quality 2way or 3way Foil-Scrim-PE Tape suitable for rough surface, high adhesive strength with big adhesive volume



PRODUCT DESCRIPTION

Foil-Scrim-PE backing (Foil: 18u / 2-way or 3-way Scrim / PE:38U), combined with a high performance Rubber Resin adhesive, protected by an easy-release silicone release paper.



TYPICAL PHYSICAL PROPERTIES

PROPERTIES METRIC TEST METHOD
Backing Thickness 0.150±0.015mm PSTC-133
Total Thickness 0.220±0.022mm PSTC-133
Adhesive weight g/m2 Scale 135±13.5 g/m2
Adhesion to Steel ≥22 N/25mm PSTC-101
Ball Tack(Steel ball #) ≥25 # JIS Z0237
Service Temperature -20 ~ +80 °C ------------
Applying Temperature +10 ~ 40 °C ------------



TYPICAL APPLICATIONS: HVAC industry for joining and sealing Alum.-Glass Facing laminated fiberglass blanket / duct board joints and seams; joining and sealing industrial pipe insulation’ seams and connections. May also be used for other industrial uses requiring a tape with these characteristics and benefits.



PRODUCT FORM & SIZE AVAILABLE

Cut Roll width: 48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4").

Roll width:1000mm,1200mm

Length: Log roll: 45 / 50m Jumbo Roll: 500m / 750m

Tags:

0.12mm foil scrim kraft,

0.12mm fsk foil scrim kraft,

fsk foil scrim kraft 0.12mm
