160 Micron Glass Cloth Insulation Tape with Acrylic Adhesive

MOQ:	500m2
Price:	by quote
Standard Packaging:	Each column shrink packed and then in export carton.
Delivery Period:	30days
Payment Method:	T/T
Supply Capacity:	10,000m2

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin

CHINA

Certification

Model Number

Backing Material:

E-fiber Glass Cloth

Backing Thickness:

100um

Total Thickness:

160um

Adhesive Type F-Class:

Acrylic Pressure-Sensitive

Adhesion To Steel:

≥4N/10mm

Tensile Strength:

≥200N/10mm

Elongation:

Breakdown Voltage F-Class:

≥1.8kV

Service Temp.:

-30°C ~ +150°C

Tack Rolling Ball:

≤10cm

Cut Roll:

10mm~500mm Width

Roll Length:

Highlight:

160 Micron Glass Cloth Tape

Acrylic Adhesive Glass Cloth Tape

Glass Cloth Insulation Tape

Product Description

Product Overview

Glass Cloth Adhesive Tape with Acrylic Adhesive is made from a glass cloth backing coated with pressure-sensitive acrylic adhesive and supplied with an easy-release liner. The glass cloth backing provides mechanical reinforcement, while the acrylic adhesive supports bonding and component fixation in industrial applications.

With a total thickness of 160 microns and a service temperature range of -30°C to +150°C, this tape is suitable for electrical insulation, component securing, and industrial surface protection. The easy-release liner facilitates handling and application during assembly.

Technical Specifications

Property	Value
Total Thickness	160 Micron
Service Temperature	-30°C to +150°C
Adhesive Type (F-Class)	Acrylic Pressure-Sensitive

Key Advantages

Reinforced Glass Cloth Backing: Provides mechanical support for demanding industrial applications.
Pressure-Sensitive Acrylic Adhesive: Enables convenient bonding and component fixation.
Easy-Release Liner: Helps protect the adhesive surface before use and simplifies application.
Wide Service Temperature Range: Suitable for applications operating between -30°C and +150°C.

Applications

Electrical Insulation: Used for insulating and securing electrical components.
Battery and Electronics Assembly: Suitable for component fixation and insulation protection, subject to application-specific requirements.
Industrial Surface Protection: Used for protecting selected surfaces and securing materials during assembly.
Mechanical Fixation: Suitable for applications requiring a reinforced adhesive tape.

Frequently Asked Questions

1. What materials are used in this glass cloth adhesive tape?

The tape consists of a glass cloth backing, acrylic pressure-sensitive adhesive, and an easy-release liner.

2. What is the total thickness of the tape?

The specified total thickness is 160 microns (0.16 mm).

3. What is the service temperature range?

The specified service temperature range is -30°C to +150°C. Actual performance may depend on bonding conditions, exposure duration, and the materials being bonded.
