F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options

F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options
F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options
F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options

Large Image :  F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options

Product Details:
Place of Origin: China
Certification: UL
Model Number: 432/452/472
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square meters
Price: quoted as per size and quantity
Packaging Details: cartons and pallet
Delivery Time: about 30 days
Payment Terms: L/C,T/T
Supply Ability: 10000rolls per month
Contact Now

F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options

Description
Material: Aramid Paper Thickness: 0.105/0.13/0.18mm
Adhesive: Acrylic Pressure Sensitive Adhesive Breakdown Voltage: ≥ 1.8kV/2.4kV/2.8kV
Tensile Strength: ≥ 30/45/90 N/10mm Long-term Temp. Resistance: F Class/155℃
Width: 10~980mm Length: 50m
Highlight:

F-class Aramid Paper Adhesive Tape

,

155℃ Insulation Tape

,

Flame Retardant Electrical Insulation Tape

F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options
Product Description
The F-class insulation aramid paper adhesive tape is constructed from high-performance aramid paper combined with a flame-retardant acrylic pressure-sensitive adhesive. As a core material in premium electrical insulation systems, it delivers exceptional heat resistance, electrical insulation, mechanical toughness, and flame retardancy, designed for demanding applications.
Technical Specifications
Parameters Value
Thickness 0.105/0.13/0.18mm
Breakdown Voltage ≥ 1.8/2.4/2.8kV
Tensile Strength ≥ 30/45/90 N/10mm
Long-term Temperature Resistance F class/155℃
Advantages
  • Thermal Resistance: Stable at 155°C (Class F), non-melting
  • Electrical Insulation: High dielectric strength prevents breakdown
  • Flame Retardancy: Self-extinguishing, meets fire safety standards
  • Chemical Resistance: Withstands solvents, oils, and corrosion
  • Eco-Safe: Halogen-free, non-toxic, no harmful emissions
Applications
  • Coil End Wrapping: Provides F-class insulation for motor and transformer coils
  • Battery Insulation: Offers chemical-resistant protection for lithium batteries and electronic components
  • Specialty Coil Wrapping: Ideal for HVT, HID, and other high-performance electronic transformers
F-class Insulation Aramid Paper Adhesive Tape With Multiple Model Options 0
