Technical Parameters:
| Elongation |
≥3% |
| Features |
Soft And Tear-resistant |
| Fiberglass Cloth Thickness |
0.10mm |
| Material |
Glass Cloth Backing |
| Adhesive Strength to Steel |
>=4N/cm |
| Color |
White |
| Adhesive |
Pressure-sensitive Acrylic Adhesive |
| Total Thickness |
0.16mm |
| Tensile Strength |
200N/cm |
| Roll Width |
<500mm |
| Parameter |
F-Class (155°C) |
H-Class (180°C) |
| Base Material |
E-Glass Fiber (0.10mm) |
E-Glass Fiber (0.12mm) |
| Adhesive Type |
Acrylic Pressure-Sensitive |
High-Temp Silicone |
| Operating Temperature |
-40°C to +155°C |
-50°C to +180°C |
| Breakdown Voltage |
≥1.8kV |
≥2.5kV |
| Certifications |
UL Recognized, RoHS, REACH Compliant |
Advantages:
1. High Mechanical Strength: The fiberglass backing provides excellent tensile, tear, and puncture resistance, making it extremely rugged and durable.
2. Excellent Temperature Resistance: It can withstand high-temperature environments long-term and It also performs well in low-temperature conditions.
3. Strong Adhesion: Its high-performance adhesive creates a powerful bond on various surfaces.
4. Superior Chemical & Weather Resistance: It offers good resistance to most solvents, chemicals, oils, and UV light, making it suitable for harsh indoor and outdoor environments.
5. Insulation & Flame Retardancy: Fiberglass is an excellent electrical insulator and is naturally flame retardant, meeting many safety standards.
Application Fields:
1. Electronics & Electrical Industry: Primarily used for insulating and binding transformers and inductor coils, managing cables and harnesses in high-temperature environments, and masking PCB boards during soldering processes.
2. Aerospace & Automotive Industry: Typical applications include masking protection during high-temperature painting and baking processes, bundling high-temperature pipelines and wiring harnesses in engine compartments, and processing and securing composite components.
3. Construction & Building Industry: Widely applied for crack-resistant reinforcement of drywall seams, and for securing and sealing roofing waterproofing membranes, providing durable and reliable solutions.
4. Industrial Manufacturing & Repair: Common uses include surface protection for heavy machinery, temporary sealing and gasket replacement in high-temperature environments, and bundling and reinforcement for heavy-duty packaging.
