Product Description:
Product Summary: Electrical Insulation Board
The Electrical Insulation Board is a high-quality electrical insulating material designed in a board shape, providing excellent performance in various applications requiring electrical insulation. This product is commonly known as an Electrical Insulation Plate due to its functionality and structure.
Shape: Board(sheet)
Electric strength perpendicular to laminations (at 90℃±2℃ in oil), 1mm in thickness: ≥14.2kV/mm
Relative permittivity (50Hz): ≤5.5
Density: ≥1.8g/cm3
Surface: Smooth with no Significant Defect
The Electrical Insulation Board offers superior electric strength perpendicular to laminations, with a minimum value of 14.2kV/mm, ensuring reliable insulation in various electrical applications. Its relative permittivity of less than 5.5 at 50Hz allows for efficient electrical performance while maintaining stability.
With a density of at least 1.8g/cm3, this Electrical Insulation Board exhibits a durable and robust structure, suitable for demanding environments where high insulation properties are crucial. The smooth surface finish of the board ensures optimal performance and minimizes the risk of defects, guaranteeing consistent quality.
Technical Parameters:
| Water Absorption |
≤0.05% |
| Color |
Yellow |
| Shape |
Board |
| Flexural strength perpendicular to laminations(MD) |
≥340MPa |
| Surface |
Smooth/no Significant Defect |
| Breakdown voltage parallet to laminations(at 90℃±2℃ in oil) |
≥35kV |
| Relative permittivity(50Hz) |
≤5.5 |
| Tensile strength(MD) |
≥300MPa |
| Density |
≥1.8g/cm3 |
| Charpy impact strength parallel to laminations(Notched) |
≥33kJ/m2 |
Applications:
Electrical Insulation Board model number 3240 is a high-quality product originating from China, designed to meet the demanding requirements of various electrical insulation applications. With a Charpy impact strength parallel to laminations of at least 33kJ/m2, this Electrical Insulation Board provides excellent mechanical durability and resistance to impacts, making it ideal for use in scenarios where robust insulation is essential.
One of the key features of this Electrical Insulation Board is its impressive breakdown voltage parallel to laminations, which exceeds 35kV when tested at 90℃±2℃ in oil. This attribute ensures reliable performance and safety in applications where high voltage levels are present, such as in transformers, switchgear, and other electrical equipment.
The size of the Electrical Insulation Board is 102 X 202cm, offering versatility in various installation requirements. Its relative permittivity of less than 5.5 at 50Hz makes it suitable for applications where consistent electrical properties are essential for optimal performance.
Moreover, the Electric Insulation Material exhibits exceptional electric strength perpendicular to laminations, with a minimum of 14.2kV/mm thickness when tested at 90℃±2℃ in oil. This feature makes it a reliable choice for applications requiring high dielectric strength and insulation capabilities.
Overall, the Electrical Insulation Board serves as a dependable solution for a wide range of Product Application Occasions and Scenarios within the electrical industry. Its superior performance characteristics make it suitable for use in electrical panels, insulating supports, busbars, and other applications that demand high-quality Electric Insulation Plate products.
Customization:
Customize your Electrical Insulation Board (also known as Electrical Insulation Plate or Insulating Electrical Board) with the following attributes:
Model Number: 3240
Place of Origin: China
Shape: Board
Color: Yellow
Compressive strength: ≥350MPa
Charpy impact strength parallel to laminations(Notched): ≥33kJ/m2
Density: ≥1.8g/cm3
