Product Details:
|
| Adhesive Type: | Cold Weather Solvent Acrylic Adhesive | Backing Thickness: | 30um |
|---|---|---|---|
| Tensile Strength: | 12 N/25mm | Service Temperature: | -30 +120 C |
| Total Thickness: | 70 Um | Tape Finish: | Gloss Finish |
| High Light: | Cold Weather Aluminum Foil Adhesive Tape,30um Aluminum Foil Adhesive Tape,30um adhesive aluminum tape |
||
Cold weather Aluminum Foil Tape Without Liner
PRODUCT DESCRIPTION
A nominal 30 micron (1.2 mil) release coated gloss aluminum foil backing, combined with high performance cold weather solvent acrylic adhesive.
FEATURES
• Aluminum Foil Tape Without Liner makes easy application.
• Aluminum backing provides excellent reflection of both heat and light.
• Cold weather adhesive formula, excellent fast stick.
• Good at winter season application.
• Low moisture vapor transmission rate offers excellent sealing and patching performance.
TYPICAL PHYSICAL PROPERTIES
| PROPERTIES | METRIC | TEST METHOD |
| Backing Thickness | 30 Micron | PSTC-133 / ASTM D 3652 |
| Total Thickness | 70 Micron | PSTC-133 / ASTM D 3652 |
| Adhesion to Steel | 12 N/25mm | PSTC-101 / ASTM D 3330 |
| Tack Rolling Ball | 5 cm | JIS Z0237 |
| Tensile Strength | 45 N/25mm | PSTC-131 / ASTM D 3759 |
| Elongation | 3.0 % | PSTC-131 / ASTM D 3759 |
| Service Temperature | -30 ~ +120 °C | ------------ |
| Applying Temperature | +10 ~ 40 °C | ------------ |
TYPICAL APPLICATIONS: Excellent for fixing copper tube of Freezers and Refrigerator. General purpose holding, patching, sealing and masking applications – indoors and outdoors.
PRODUCT FORM & SIZE AVAILABLE
ROLL WIDTH: 48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4")
ROLL LENGTH: 50M / 100M / 150M / 200M / 250M / 300M
IMPORTANT NOTE
1. The data above are typical values only, and should not be used for specifications purpose.
2. Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: Cut Roll: ±0.3m, Jumbo Roll ±0.5%.
STORAGE & SHELF LIFE: 12 months when stored at 21°C (70°F) / 50% relative humidity out of direct sunlight.
