Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive

Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive
Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive
Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive

Large Image :  Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive

Product Details:
Place of Origin: CHINA
Certification: RoHS
Model Number: K2321
Payment & Shipping Terms:
Minimum Order Quantity: 500m2
Price: based on sizes and quantity
Packaging Details: Export carton case
Delivery Time: 35 working days
Payment Terms: L/C,T/T
Supply Ability: 50,000m2 per month
Contact Now

Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive

Description
Features: Polyimide Film Adhesive Tape Product Category: Polyimide Film Adhesive Tape
Halogen Free: Yes Thickness: 30um~100um
Standard Roll Length: 33 Meters Base Material Thickness Options: 7.5 µm, 12.5 µm, 25 µm, And 50 µm
BDV: ≥2.0KV Working Temp.: 180℃ (long Term)
Temperature Range: -73℃ To 260℃ Tensile Strength: ≥25N/10mm
Adhesion: ≥1.8N/10mm Application: High Temperature Applications
Highlight:

Polyimide adhesive tape with silicone adhesive

,

Pressure sensitive polyimide film tape

,

Polyimide tape 30um to 100um thickness

Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive
This specialized polyimide adhesive tape is engineered for demanding working conditions, combining high-temperature resistance, electrical insulation, and strong bonding properties. It provides durable and reliable adhesion in complex environments such as PCB insulation, with multiple thickness options available to meet customized requirements.
Technical Specifications
Material Polyimide Film
Adhesive Type Pressure Sensitive Silicone Adhesive
Thickness 30um~100um
Key Advantages
  • Triple Performance Integration: Simultaneously delivers excellent high-temperature resistance, high dielectric strength, and stable strong adhesion for demanding working conditions.
  • Environmental Adaptability: Maintains stable physical properties under high temperatures, chemical solvents, and sudden temperature changes, resisting embrittlement or peeling.
  • Precision Control: Customizable thickness (typical range 0.03mm-0.15mm), balancing flexibility and mechanical protection for precision industrial applications.
Primary Applications
  • Electronic Circuit Protection: Used for PCB trace insulation, gold finger shielding, and high-temperature protection of electronic components to prevent short circuits and signal interference.
  • High-Temperature Process Protection: Applied to reflow carrier surfaces, hot press heads, and high-temperature equipment for heat insulation, anti-adhesion, and wear resistance.
  • Aerospace & Automotive Electronics: Provides lightweight insulation and environmental protection for engine wiring harnesses, battery modules, and sensor packaging.
Polyimide Adhesive Tape 30um~100um Thickness With Pressure Sensitive Silicone Adhesive 0

Tag:

25um Polyimide Film Adhesive Tape,

Polyimide Film Adhesive Tape H Grade,

Single Side Coated polyimide high temperature tape
