BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film

BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film
BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film
BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film

Large Image :  BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film

Product Details:
Place of Origin: China
Certification: UL
Model Number: 6052
Payment & Shipping Terms:
Minimum Order Quantity: 1 roll
Price: basing as thickness and quantity
Packaging Details: carton and pallet
Delivery Time: about 15 days
Payment Terms: T/T
Supply Ability: 1000000sq.m per month
Contact Now

BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film

Description
Material: Biaxially Oriented Polyimide Film (BOPI Film) Thickness: 7.5~50um
Tensile Strength(longitudinal): ≥150MPa Tensile Strength(transverse): ≥150MPa
Break Elongation（longitudinal）: ≥40% Break Elongation(transverse): ≥40%
Power Frequency Electrical Strength (average Value): ≥220 Power Frequency Electrical Strength (Individual Value): ≥150
Surface Resistivity: ≥1.0×10 14Ω Volumetric Resistivity: ≥1.0×10 10Ωm
Highlight:

UL-certified polyimide film

,

BOPI film with warranty

,

50μm thickness polyimide tape

BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film
The BOPI film offers exceptional thermal stability, mechanical strength, and electrical insulation for demanding applications. Its biaxial orientation ensures superior dimensional integrity, while corona-treated surfaces provide excellent adhesion.
Product Specifications
Material Biaxially Oriented Polyimide Film (BOPI Film)
Thickness 7.5~50μm
Key Features
  • Thermal & Mechanical Excellence: Withstands extreme temperatures and stress, delivering high tensile strength, tear resistance, and reliable dimensional stability.
  • Electrical & Chemical Reliability: Provides superior insulation and dielectric performance while resisting solvents, oils, and harsh chemicals.
  • Built-In Safety & Durability: Features inherent flame-retardant and self-extinguishing properties that meet rigorous safety standards.
Applications
  • Flexible Heaters & Sensors: Provides a thermally stable and durable dielectric layer for high-performance flexible heating elements and sensor arrays.
  • High-Temperature Processing Films: Serves as an ideal barrier and release film in environments demanding exceptional thermal resilience.
  • EMI Shielding Components: Acts as a robust substrate for metallized films, delivering effective electromagnetic interference (EMI) shielding.
BOPI Film With UL-Certified 7.5~50μm Thickness Polyimide Film 0

Tag:

25um Polyimide Film Adhesive Tape,

Polyimide Film Adhesive Tape H Grade,

Single Side Coated polyimide high temperature tape
