Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance

Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance
Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance

Large Image :  Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance

Product Details:
Place of Origin: China
Certification: UL
Model Number: 6052
Payment & Shipping Terms:
Minimum Order Quantity: 1 roll
Price: basing as thickness and quantity
Packaging Details: carton and pallet
Delivery Time: about 15 days
Payment Terms: T/T
Supply Ability: 1000000sq.m per month
Contact Now

Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance

Description
Thickness: 12.5~50um Tensile Strength: ≥150MPa
Relative Permittivity: ~3.5 Surface Resistivity: ≥1.0×10^14Ω
Volumetric Resistivity: ≥1.0×10^10Ωm Thermal Shrinkage: ≤ 3.5%
Temp. Index: ≥180℃ Application: Used As A Cover Film For Flexible Circuits And For High-temperature Electrical Insulation
Highlight:

12.5-50μm Thickness BOPI Film

,

≥150MPa Tensile Strength Polyimide Film Adhesive Tape

,

≥180℃ Temperature Index Biaxially Oriented Polyimide Film

Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance
Product Description
The BOPI film is manufactured through advanced casting and biaxial stretching processes, available in thicknesses of 12.5/25/35/40/50μm, delivering enhanced comprehensive performance. It undergoes precision corona treatment to ensure optimal adhesion for coating, lamination, and metallization processes. UL-certified for reliability, it provides high-performance solutions for demanding industrial applications.
Technical Specifications

Parameters

Value
Thickness Range 12.5μm-50μm
Temperature Index ≥180℃
Tensile Strength ≥150 MPa
Volumetric Resistivity ≥1.0×10¹⁰Ωm
Surface Resistivity ≥1.0×10¹⁴Ω
Relative Permittivity ~3.5
Thermal Shrinkage ≤ 3.5%
Key Advantages
  • Broad-Temperature Stability: Maintains stable performance across an extreme range of -240°C to +260°C
  • High Strength & Toughness: Delivers high tensile strength, rigidity, tear resistance, and dimensional stability
  • Premium Insulation & Safety: Provides superior electrical insulation with inherent flame retardancy
  • Chemical Resistance: Highly resistant to most organic solvents, oils, and greases
Applications
  • Flexible Circuit Substrates: Ideal as a base material and cover film for flexible printed circuits (FPC)
  • High-Temperature Insulation: Key insulating component for specialty wires, motors, and transformers
  • Flexible Functional Components: Preferred dielectric and protective material for flexible heaters and sensors
Biaxially Oriented Polyimide (BOPI) Film With Enhanced Comprehensive Performance 0

Tag:

25um Polyimide Film Adhesive Tape,

Polyimide Film Adhesive Tape H Grade,

Single Side Coated polyimide high temperature tape
