Dual-Side Corona Treated BOPI Film 7.5-50μm with UL Certification

Large Image : Dual-Side Corona Treated BOPI Film 7.5-50μm with UL Certification

Product Details:

Place of Origin:	China
Certification:	UL
Model Number:	6052

Payment & Shipping Terms:

Minimum Order Quantity:	1 roll
Price:	basing as thickness and quantity
Packaging Details:	carton and pallet
Delivery Time:	about 15 days
Payment Terms:	T/T
Supply Ability:	1000000sq.m per month

Contact Now

Dual-Side Corona Treated BOPI Film 7.5-50μm with UL Certification

Description

Material:	Biaxially Oriented Polyimide Film (BOPI Film)	Thickness:	7.5~50um
Tensile Strength(longitudinal):	≥150MPa	Tensile Strength(transverse):	≥150MPa
Break Elongation（longitudinal）:	≥40%	Break Elongation(transverse):	≥40%
Power Frequency Electrical Strength (average Value):	≥220	Power Frequency Electrical Strength (Individual Value):	≥150
Surface Resistivity:	≥1.0×10 14Ω	Volumetric Resistivity:	≥1.0×10 10Ωm
Highlight:	Dual-Side Corona Treated BOPI Film , UL Certified Polyimide Film , BOPI Film 7.5-50μm

Dual-Side Corona Treated Biaxially Oriented Polyimide Film (BOPI Film) thickness 7.5-50μm with UL Certification

Product Specifications

Attribute	Value
Material	Biaxially Oriented Polyimide Film (BOPI Film)
Thickness	7.5~50μm
Tensile strength (longitudinal)	≥150MPa
Tensile strength (transverse)	≥150MPa
Break elongation (longitudinal)	≥40%
Break elongation (transverse)	≥40%
Power frequency electrical strength (average value)	≥220
Power frequency electrical strength (individual value)	≥150
Surface resistivity	≥1.0×10¹⁴Ω
Volumetric resistivity	≥1.0×10¹⁰Ωm

Product Description

This is a Dual-Side Corona Treated Biaxially Oriented Polyimide Film (BOPI Film), thickness range 7.5-50μm with UL Certification.

Biaxially Oriented Polyimide Film (BOPI Film): Engineered for Extreme Performance

Unlike cast films, our biaxially oriented PI film undergoes advanced stretching technology that aligns polymer chains in both machine (MD) and transverse (TD) directions.
