1.5mm Vermiculite Coated Fiberglass Cloth 1000mm Wide 800℃ Heat Shield
  • name
  • name
  • name

1.5mm Vermiculite Coated Fiberglass Cloth 1000mm Wide 800℃ Heat Shield

MOQ: 20rolls
Price: basing size and quantity
Standard Packaging: cartons and pallet
Delivery Period: about 30 days
Payment Method: T/T
Supply Capacity: 500rolls per month
Detail Information
Product Description
Ratings & Reviews
Detail Information
Place of Origin
China
Model Number
1.5mm BV
Width:
1000mm
Roll Length:
50/100m
Weight:
1060G/sq.m±5%
Weave:
Plain
Impregnated:
Vermiculite
Color:
Black Or Tan
Thickness:
1.5mm
Temperature Resistance:
800℃
Transient Temperature:
1200℃
Usage:
Heat Shield, Flange And Valve Covers, Welding Curtains, Expansion Joins And Equipment
Highlight:

1.5mm vermiculite fiberglass heat shield

,

1000mm wide heat resistant insulation

,

800℃ high temperature fiberglass cloth

Product Description
1.5mm Black Vermiculite Coated Fiberglass Cloth 50/100m Roll Length 800℃ Heat Shield
Product Specifications
Attribute Value
Width 1000mm
Roll length 50/100m
Weight 1060G/sq.m±5%
Weave Plain
Impregnated Vermiculite
Color Black or tan
Thickness 1.5mm
Temperature Resistance 800℃
Transient Temperature 1200℃
Usage Heat shield, flange and valve covers, welding curtains, expansion joins and equipment
Product Description

This high-performance vermiculite-coated fiberglass cloth is manufactured through a specialized process that combines vermiculite with fiberglass fabric. The dark-colored design features a 1.5mm thickness and 1060g/m² weight, maintaining excellent mechanical properties with outstanding weather resistance for industrial thermal protection applications.

The heat-treated natural mineral forms a unique microporous structure, with testing confirming the material can withstand:

  • Instantaneous temperatures up to 1200°C
  • Continuous operation at 800°C

Additional performance advantages include:

  • High tensile strength
  • Superior corrosion resistance
  • Excellent electrical insulation
  • Flame retardant properties

Available in standard 1000mm width with customizable processing options, this material is widely used in:

  • Metallurgy
  • Shipbuilding
  • Petrochemical
  • Power generation industries

The cloth maintains stable physical properties and protective performance even under prolonged exposure to high temperatures and chemical corrosion, ensuring industrial equipment safety. Its lightweight yet high-performance design reduces construction difficulty while maintaining protective effectiveness.
