1.4mm Black Vermiculite Coated Fiberglass Cloth for Heat Shield

1.4mm Black Vermiculite Coated Fiberglass Cloth for Heat Shield
1.4mm Black Vermiculite Coated Fiberglass Cloth for Heat Shield 1.4mm Black Vermiculite Coated Fiberglass Cloth for Heat Shield 1.4mm Black Vermiculite Coated Fiberglass Cloth for Heat Shield

Large Image :  1.4mm Black Vermiculite Coated Fiberglass Cloth for Heat Shield

Product Details:
Place of Origin: China
Model Number: 2500BV
Payment & Shipping Terms:
Minimum Order Quantity: 20rolls
Price: basing size and quantity
Packaging Details: cartons and pallet
Delivery Time: about 30 days
Payment Terms: T/T
Supply Ability: 500rolls per month
Contact Now

1.4mm Black Vermiculite Coated Fiberglass Cloth for Heat Shield

Description
Width: 1000mm Roll Length: 50/100m
Base Fabric Weight: 810G/sq.m±5% Weave: Plain
Impregnated: Vermiculite Color: Black Or Tan
Thickness: 1.4mm Coated Weight: 950G/sq.m±5%
Temperature Resistance: 800℃ Usage: Heat Shield, Flange And Valve Covers, Welding Curtains, Expansion Joins And Equipment
Highlight:

1.4mm black vermiculite fiberglass cloth

,

heat shield fiberglass cloth

,

heat resistant insulation tape with warranty

1.4mm Thickness Black Fiberglass Cloth Coated With Vermiculite On Both Sides For Heat Shield
Product Specifications
Attribute Value
Width 1000mm-2000mm
Roll length 50-100m
Base fabric weight 810G/sq.m±5%
Weave Plain
Impregnated Vermiculite
Color Black
Thickness 1.4mm
Coated weight 950G/sq.m±5%
Temperature Resistance 800℃
Usage Heat shield, flange and valve covers, welding curtains, expansion joins and equipment
Product Description
Our vermiculite-coated fiberglass cloth is a premium non-asbestos solution designed for demanding high-temperature applications. This innovative material combines the strength of fiberglass with the exceptional thermal insulation properties of vermiculite.
Key Features
  • Superior thermal protection: Withstands short-term temperatures up to 1200°C and continuous service at 800°C
  • Versatile applications: Ideal for heat shields, welding curtains, valve covers, and industrial equipment insulation
  • Optimized composition: 1.4mm thickness with 950G/sq.m coating weight for balanced performance
  • Durable construction: Plain weave fiberglass base (810G/sq.m) provides excellent mechanical strength
  • Flexible sizing: Available in widths from 1000mm to 2000mm and roll lengths of 50-100m
Performance Benefits
The unique vermiculite coating expands under heat to create a protective insulating layer, while the fiberglass substrate maintains structural integrity. This synergistic combination delivers:
  • Enhanced fireproofing capabilities
  • Reliable thermal insulation in extreme environments
  • Lightweight yet durable protection
  • Resistance to heat transfer and thermal shock
Industrial Applications
This high-performance material serves critical insulation needs across multiple industries including metallurgy, shipbuilding, petrochemical, and power generation. Its adaptability makes it suitable for various challenging working environments where thermal management is essential.
