Halogen Free Polyimide Film Adhesive Tape RoHS Compliant for -73.C to 280.C Temperature Range

Certification
China UN.Tex (Dalian) Co.,Ltd certification
China UN.Tex (Dalian) Co.,Ltd certification
I'm Online Chat Now

Halogen Free Polyimide Film Adhesive Tape RoHS Compliant for -73.C to 280.C Temperature Range

Halogen Free Polyimide Film Adhesive Tape RoHS Compliant for -73.C to 280.C Temperature Range
Halogen Free Polyimide Film Adhesive Tape RoHS Compliant for -73.C to 280.C Temperature Range Halogen Free Polyimide Film Adhesive Tape RoHS Compliant for -73.C to 280.C Temperature Range

Large Image :  Halogen Free Polyimide Film Adhesive Tape RoHS Compliant for -73.C to 280.C Temperature Range

Product Details:
Place of Origin: China
Model Number: 2421
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square meters
Price: quoted as per size and quantity
Packaging Details: cartons and pallet
Delivery Time: about 35 days
Payment Terms: T/T
Supply Ability: 10000rolls per month

Halogen Free Polyimide Film Adhesive Tape RoHS Compliant for -73.C to 280.C Temperature Range

Description
Material: Polyimide Film Elongation: ≥40%
RoHS Compliant: Yes Tensile Strength: ≥42N/10mm
Product Name: Polyimide Film Adhesive Tape Adhesion To Steel: ≥2.2N/10mm
Temperature Range: -73℃~280℃ Halogen Free: Yes
Working Temp.: 220℃(long Time), 280℃(short Time) Dielectric Strength: ≥80kv/mm
High Light:

RoHS Compliant Polyimide Film Adhesive Tape

,

Halogen Free Polyimide Film Adhesive Tape

Product Description:

Our Polyimide Film Adhesive Tape has a Tensile Strength of ≥42N/10mm, which means it can withstand pressure and tension without breaking or tearing. This feature makes it ideal for applications that require a high level of durability.

The Temperature Range of our Polyimide Film Adhesive Tape is -73℃~280℃, making it suitable for use in extreme temperatures. It can withstand both low and high temperatures without losing its adhesive properties, making it a reliable choice for various applications.

Our Polyimide Film Adhesive Tape has a Dielectric Strength of ≥80KV/mm, which means it can resist electrical breakdown(BDV>4kv). This feature makes it an excellent choice for slot liner insulation, where electrical insulation is necessary.

The Elongation of our Polyimide Film Adhesive Tape is ≥40%, which means it can stretch and bend without breaking. This feature makes it an excellent choice for applications that require flexibility and movement.

Our Polyimide Film Adhesive Tape is a reliable and cost-effective solution for various electronic applications. Its high-performance features make it an ideal choice for slot liner insulation, coverlay or stiffener in F-PCB, and other applications where durability, temperature resistance, and electrical insulation are essential.



Features:

  • Product Name: Polyimide Film Adhesive Tape
  • Dielectric Strength: ≥80KV/mm
  • Material: Polyimide Film
  • Adhesive: Pressure Sensitive Silicone Adhesive
  • Adhesion: ≥2.2N/10mm
  • Low temperature resistant
  • High temperature resistant
  • Excellent balance of electrical, chemical and physical property


Technical Parameters:

RoHS Compliant Yes
Material Polyimide Film
Elongation ≥40%
Color Amber
Insulation Resistance ≥10^13Ω
Halogen Free Yes
Adhesive Pressure Sensitive Silicone Adhesive
Dielectric Strength ≥80.0KV/mm
Adhesion ≥2.2N/10mm
Thickness 55um~70um

This Polyimide Film Adhesive Tape is suitable for wire & cable insulation, slot liner insulation and other applications where high temperature resistance and excellent electrical insulation properties are required.



Applications:

With a thickness range of 55um~70um, the product is suitable for use as a coverlay or stiffener in F-PCBs. It provides excellent insulation to circuitry and helps to protect against damage from environmental elements such as moisture or dust.

The temperature range of -73℃~280℃ makes the Polyimide Film Adhesive Tape ideal for use in both high and low-temperature environments. This makes it perfect for applications such as wire & cable insulation, where it provides a reliable and durable insulation solution.

With an elongation of ≥40%, the tape is flexible and can conform easily to irregular surfaces. This makes it perfect for use in complex applications where a high degree of flexibility is required.

Overall, the Polyimide Film Adhesive Tape is a versatile product that can be used in a wide range of applications. It is perfect for use as a coverlay or stiffener in F-PCBs, wire & cable insulation, and other applications where high-temperature resistance, flexibility, and durability are required.
