Home ProductsHeat Resistant Insulation Tape

UL certified 50m Length Heat Resistant Insulation aramid paper with Silicone Pressure-Sensitive Adhesive

Certification
China UN.Tex (Dalian) Co.,Ltd certification
China UN.Tex (Dalian) Co.,Ltd certification
I'm Online Chat Now

UL certified 50m Length Heat Resistant Insulation aramid paper with Silicone Pressure-Sensitive Adhesive

UL certified 50m Length Heat Resistant Insulation aramid paper with Silicone Pressure-Sensitive Adhesive
UL certified 50m Length Heat Resistant Insulation aramid paper with Silicone Pressure-Sensitive Adhesive UL certified 50m Length Heat Resistant Insulation aramid paper with Silicone Pressure-Sensitive Adhesive

Large Image :  UL certified 50m Length Heat Resistant Insulation aramid paper with Silicone Pressure-Sensitive Adhesive

Product Details:
Place of Origin: China
Certification: UL
Model Number: 4332
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square meters
Price: quoted as per size and quantity
Packaging Details: cartons and pallet
Delivery Time: about 35 days
Payment Terms: L/C, T/T
Supply Ability: 10000rolls per month

UL certified 50m Length Heat Resistant Insulation aramid paper with Silicone Pressure-Sensitive Adhesive

Description
Material: Aramid Paper BDV: ≥2KV
Thickness: 0.1mm Tensile Strength: ≥165N/25mm
Elongation At Break: ≥4% Color: White
Adhesion To Steel: ≥7.5N/25mm Length: 50m
High Light:

Heat Resistant Insulation aramid paper

,

UL certified Insulation aramid paper

,

50m Insulation aramid paper

Product Description:

Heat Resistant Insulation Tape

Heat Resistant Insulation Tape is an essential product for electrical insulation, specifically designed to meet the demanding requirements of electrical plastic case. It is made from high-quality Aramid Paper material, known for its excellent thermal and electrical insulation properties.

Product Overview

This heat resistant tape is classified as H Class, which means it can withstand high temperatures up to 180℃ continuously. It is an ideal choice for applications that require heat resistance and electrical insulation, making it suitable for a variety of industries such as electronics, automotive, and aerospace.

Adhesive

The tape is coated with a high-performance silicone pressure-sensitive adhesive, which provides excellent adhesion to various surfaces. The adhesive has a strong bonding strength, making it suitable for long-term use without worrying about it peeling off easily.

Tensile Strength

The tape has a minimum tensile strength of 165N/25mm, ensuring its durability and ability to withstand tension and stretching. This feature makes it ideal for applications that require a strong and reliable adhesive, such as securing wires and cables.

Material

The tape is made from Aramid Paper material, which is a type of synthetic fiber known for its exceptional strength and heat resistance. This material is also lightweight and flexible, making it easy to handle and apply on different surfaces.

BDV

The tape has a minimum breakdown voltage (BDV) of 2KV, which means it can withstand high voltage without breaking down. This feature is crucial for electrical insulation applications as it ensures the safety and reliability of the product.

Key Features
  • H Class heat resistance
  • Silicone pressure-sensitive adhesive
  • High tensile strength
  • Aramid Paper material
  • BDV of 2KV
Applications

Heat Resistant Insulation Tape is widely used in various industries, including:

  • Electronics
  • Automotive
  • Aerospace
  • Telecommunications
  • Power generation

It is suitable for applications such as:

  • Electrical insulation of plastic cases
  • Securing wires and cables
  • Coil wrapping
  • Transformer insulation

Overall, Heat Resistant Insulation Tape is a reliable and versatile product that provides excellent heat resistance and electrical insulation. Its high-quality adhesive and material make it a top choice for various applications in different industries. Trust this tape to keep your electronic components safe and secure.



Features:

  • Product Name: Heat Resistant Insulation Tape
  • Heat class: H Class
  • Long-term temperature resistance: -55℃~180℃
  • Length: 50m
  • Elongation at break: ≥4%
  • Type: Flame Retardant
  • Suitable for difficult-to-stick silicone release paper
  • Suitable for electrical plastic case
  • For high temperature protection


Technical Parameters:

AttributeDescription
Product NameHeat Resistant Insulation Tape
Heat ClassH Class
TypeFlame Retardant
Length50m
AdhesiveSilicone Pressure-sensitive
MaterialAramid Paper
Tensile Strength≥165N/25mm
Long-term Temperature Resistance-55℃~180℃
Width10mm~980mm
Adhesion to Steel≥7.5N/25mm
Thickness0.1mm
Key FeaturesElectrical Grade Low Shrinkage Polyester Film, Joint Bonding, Heat Resistant, Flame Retardant


Applications:

Heat Resistant Insulation Tape - Model Number: 4332

Place of Origin: China
Length: 50m
Color: White
Material: Aramid Paper
Width: 10mm~980mm
Thickness: 0.1mm
The Heat Resistant Insulation Tape (Model Number: 4332) is a high-quality electrical insulation tape that is designed to withstand high temperatures and provide reliable insulation. Made from aramid paper material, this tape is known for its exceptional strength and durability.
The tape is coated with a layer of electrical grade low shrinkage polyester film for added protection and insulation. The combination of aramid paper and PET film makes it ideal for use in high heat environments, making it suitable for a variety of applications.
The adhesive used in this tape is silicone-based, which ensures a strong and secure bond. This makes it easy to apply on different surfaces, even in challenging conditions. The silicone adhesive also provides excellent resistance to heat and high temperatures, making it the perfect choice for electrical insulation in hot environments.
One of the key features of this tape is its high temperature resistance. It can withstand temperatures of up to 300°C, making it suitable for use in electrical equipment and wiring that is exposed to extreme heat. This makes it an essential tool for electricians and technicians working in industries such as manufacturing, automotive, and aerospace.
The Heat Resistant Insulation Tape is available in a variety of widths, ranging from 10mm to 980mm, making it suitable for different applications. Its length of 50m also ensures that you have enough tape to complete your tasks without the need for frequent replacements.
Whether you need to insulate electrical connections, wires, or components, the Heat Resistant Insulation Tape is a reliable and durable option. Its high-quality materials and design make it a top choice for professionals and DIY enthusiasts alike. So why wait? Get your hands on this heat-resistant tape today and experience its exceptional performance.



Customization:

Heat Resistant Insulation Tape 4332 Customization Services

Model Number: 4332
Place of Origin: China
Heat class: H Class
Adhesion to steel: ≥7.5N/25mm
Elongation at break: ≥4%
Material: Aramid Paper
Thickness: 0.1mm
This heat resistant insulation tape is specially designed for joint bonding and electrical insulation. Made with high-quality aramid paper and an electrical grade low shrinkage polyester film, it offers excellent adhesion to steel with a minimum strength of 7.5N/25mm. Its elongation at break of ≥4% ensures durability and flexibility. With a heat class of H Class, it provides exceptional high temperature resistance. Originating from China, this product is customizable to meet your specific needs and requirements.



Packing and Shipping:

Product Name: Heat Resistant Insulation Tape

Packaging and Shipping:

  • Each roll of Heat Resistant Insulation Tape is packed in a durable and secure plastic bag.
  • Multiple rolls are then packed in a strong and sturdy corrugated box for extra protection during shipping.
  • The box is labeled with product name, quantity, and any other necessary information.
  • We also offer customized packaging options to meet specific customer requirements.
  • Our products are shipped through reliable and reputable courier services, such as FedEx, DHL, and UPS, to ensure timely and safe delivery.
  • For bulk orders, we can arrange for sea or air freight shipment.

Thank you for choosing our Heat Resistant Insulation Tape. We strive to provide high-quality products and excellent customer service. Please do not hesitate to contact us for any further assistance.
