Product Details:
|
| Adhesive Type: | Silicone Pressure Sensitive Adhesives | Backing Thickness: | 25 Micron/1.0 Mil |
|---|---|---|---|
| Heat Resistant: | B Grade | Tensile Strength: | 40 N/10mm |
| Base Material: | Biaxially Oriented Polyester Film | Colors: | Transparent, Yellow, White, Black Etc. |
| High Light: | Blue pet cloth tape,pet cloth tape B Grade,25 Micron pet silicone tape |
||
PET splicing tape / PET insulation adhesive tape / PET jointing tape
PET Insulation tape is used for coil wrapping of motors and electronic transformers, capacitor dielectric fixing, motor lead wire bundling,
And other electrical products that need insulation wrapping and marking.
White and black products are opaque and act as cursor tracking signs.
Base material: biaxially oriented polyester film
Adhesive: preferably imported improved Silicone pressure sensitive adhesives
| Biaxially oriented polyester film | |
| Silicone pressure sensitive adhesives |
TYPICAL PHYSICAL PROPERTIES
| PROPERTIES | METRIC | ENGLISH | TEST METHOD |
| Film Thickness | 25 Micron | 1.0 Mil | PSTC-133 / ASTM D 3652 |
| Total Thickness | 55 Micron | 2.4 Mil | PSTC-133 / ASTM D 3652 |
| Adhesion to Steel | 8 N/25mm | 28.8 Oz./In. | PSTC-101 / ASTM D 3330 |
| BDV | 3 kV | ||
| Tensile Strength | 40N/10mm | ||
| Elongation | 55% | 55% | PSTC-131 / ASTM D 3759 |
| Dielectric Loss | 0.98 | ------------ | |
| Heat-resistant class | B grade | ------------ |
TYPICAL APPLICATIONS
Primarily used for connect, join, seal and patch flexible air ducts and air connectors, can also be used in metal and metal connections.
PRODUCT FORM & SIZE AVAILABLE
Cut Roll: 5mm ~ 1000mm.
IMPORTANT NOTE
1. The data above are typical values only, and should not be used for specifications purpose.
2. Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: Cut Roll: ±0.3m, Jumbo Roll ±0.5%.
