Product Details:
|
| Adhesive Type: | Silicone Adhesive | Backing Thickness: | 35 Micron |
|---|---|---|---|
| Heat Resistant: | F Grade | Tensile Strength: | ＞165 N/25mm |
| Base Material: | Biaxially Oriented Polyester Film | Colors: | Transparent, Yellow, White, Black Etc. |
| High Light: | Silicone PET Adhesive Tape,PET Adhesive Tape 35 Micron,F Grade pet tapes |
||
PET Insulation tape
Color: Blue (Other color on order)
Base material: biaxially oriented polyester film
Adhesive: Silicone adhesive
TYPICAL PHYSICAL PROPERTIES
| PROPERTIES | DATA |
| Film Thickness | 35 ± 2 Micron |
| Total Thickness | 90 ± 5 Micron |
| Adhesion to Steel | ≥10 N/25mm |
| Tensile Strength | ≥165N/25mm |
| Elongation | ≥60% |
| Holding power (10x20mm/150°C+200g/30min) | ≤1mm |
| Heat-resistant class | F grade |
TYPICAL APPLICATIONS
1. Strong adhesion strength. Suitable for joint of the silicone releasing paper, organic material etc
2. Heat resistant, not easy to deform.
PRODUCT FORM & SIZE AVAILABLE
Cut Roll: 10mm ~ 500mm.
IMPORTANT NOTE
1. The data above are typical values only, and should not be used for specifications purpose.
